Open Type Two Roll Rubber Mixing Mill Machine 6in 26 Inch For Rubber Processing

Brand Name : honghesheng

Model Number : XK450

Certification : CE

Place of Origin : CHINA

MOQ : 1 SET

Price : USD25000-6000/SET

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 200SETS/MONTH

Packaging Details : wood package /20/40GP/HC

After-sales service provided : Engineers available to service machinery overseas,Field installation,commissioning and training,Video technical support

Type : Open Mixing Mill

Roller hardness : 50~60HRC

Bush : nylon bush,bearing bush,ball bearing Bush

Voltage : 380V,Customer's Request,380V/50HZ,220/380V,AC380V

Power(w) : 37kw,4.5KW,20KW,5KW for lab two roll mill

Weight : 5200kgs,1000kg,2T

Dimension(l*w*h) : 1100*700*1200mm,1226x830x1295mm,1*1.1*1.4(M),1100*650*1500,1160*920 *1370mm

Warranty : 1 Year

Condition : New

Contact Now

China Top Manufacturer Open Type Two Roll Rubber Mixing Mill Machine For Rubber Processing ,Two Roll Mixer ,6''-26inch

Application :

Rubber mixing mill is used for mixing and kneading raw rubber, synthetic rubber, thermoplastics or E.V.A.with chemicals into final materials. The final materials can be fed to calender, hot presses or other processing machine for making rubber or plastic products.

Open Type Two Roll Rubber Mixing Mill Machine 6in 26 Inch For Rubber Processing

parameters

Parameter

Parameter/model		XK-160	XK-250	XK-300	XK-360	XK-400
Roll diameter(mm)		160	250	300	360	400
Roll working length (mm)		320	620	750	900	1000
Capacity (kg/batch)		4	15	20	30	40
Front roll speed (m/min)		10	16.96	15.73	16.22	18.78
Roll speed ratio		1:1.21	1:1.08	1:1.17	1:1.22	1:1.17
Motor power (KW)		7.5	18.5	22	37	45
Size (mm)	Length	1104	3230	4000	4140	4578
	Width	678	1166	1600	1574	1755
	Height	1258	1590	1800	1800	1805
Weight (KG)		1000	3150	5000	6892	8000

Parameter/model		XK-450	XK-560	XK-610	XK-660	XK-710
Roll diameter(mm)		450	560/510	610	660	710
Roll working length (mm)		1200	1530	2000	2130	2200
Capacity (kg/batch)		55	90	120-150	165	150-200
Front roll speed (m/min)		21.1	25.8	28.4	29.8	31.9
Roll speed ratio		1:1.17	1:1.17	1:1.18	1:1.09	1:1.15
Motor power (KW)		55	90/110	160	250	285
Size (mm)	Length	5035	7100	7240	7300	8246
	Width	1808	2438	3872	3900	3556
	Height	1835	1600	1840	1840	2270
Weight (KG)		12000	20000	44000	47000	51000

Detailed picture

Open Type Two Roll Rubber Mixing Mill Machine 6in 26 Inch For Rubber Processing
