EVA Foam Rubber Sheets Vulcanizing Press EVA Mat Foaming Machine 4 Working Layers

Qingdao Honghesheng Industry Co., Ltd.
Contact Now

EVA Foam Rubber Sheets Vulcanizing Press EVA Mat Foaming Machine 4 Working Layers

Brand Name : HHS

Model Number : 200-1350T

Certification : CE ISO

Place of Origin : CHINA

MOQ : 1 set

Price : USD:10000-40000 /SET

Payment Terms : D/A, L/C, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100 sets/month

Delivery Time : 40 working days

Packaging Details : wood package /20-40 container

Total Pressure : 200-1350t

Plates Size : 500-1600mm

Product : eva pp

Distance : 150-200mm

Cylinder : 380-1016

Dimension(L*W*H) : 1880*780*1660

Voltage : Request

Warranty : 2 years

Power : 15kw

Application : EVA slipper making

Contact Now

EVA Foaming Sheet Making Machine / EVA Foaming Vulcanizing Press

Foam Rubber Vulcanizer Supplier



Usage

FOUR POLES HYDRAULIC PRESS is suitable to vulcanize and form EVA, PE, PVC, the SBR foaming materials.

1.Used for producting of foaming slippers,foaming sheet, floor MATS, sports protective material, beach shoes, insulation materials,life jacket,sponge and other rubber products;

2.Main frame uses casting steel,piston adopts chilled cast iron,with surface hardness is HR-70.



Machine Features:

  • strong rigidity, small deformation
  • pressure, and high back pressure
  • open mold fast
  • with cavity pressure function, can satisfy the production of high, medium and low grade of product process requirements.
  • the special structure of the hot plate design, uniform heating temperature



Technical Parameter

Type XLB-1200X1200X4 XLB-1400X1500X6 XLB-1500x1500x6
Total Pressure(MN) 5.00 8.00 10.00
Plate Size(mm) 1200x1200 1400x1500 1500x1500
Plate Clearance(mm) 150 150 150
Working Stroke 500 800 800
Plate Pressure(Mpa) 3.5 3.8 4.5
Motor Power(kw) 18.5 26 33
Overall Size(mm) 2400x2100x3200 2650x2400x3600 2750x2400x3600
Weight(kgs) 22,000 38,000 48,000


Our Advantages:

1) Raw material:our raw materials are purchased from reputed suppliers,such as Siemens----good quality from the origin;

2) Design:Our engineers are experienced with professional knowledge----scientific and suitable design for you;

3) Make process:Products are processed in a high level automatic CNC center by experienced workers----always endeavoring to do still better;

4) Through the ISO9001 certification, and establish strict quality management system.



Machine Pictures

EVA Foam Rubber Sheets Vulcanizing Press EVA Mat Foaming Machine 4 Working Layers

EVA Foam Rubber Sheets Vulcanizing Press EVA Mat Foaming Machine 4 Working Layers

EVA Foam Rubber Sheets Vulcanizing Press EVA Mat Foaming Machine 4 Working LayersEVA Foam Rubber Sheets Vulcanizing Press EVA Mat Foaming Machine 4 Working LayersEVA Foam Rubber Sheets Vulcanizing Press EVA Mat Foaming Machine 4 Working LayersEVA Foam Rubber Sheets Vulcanizing Press EVA Mat Foaming Machine 4 Working Layers

EVA Foam Rubber Sheets Vulcanizing Press EVA Mat Foaming Machine 4 Working Layers

EVA Foam Rubber Sheets Vulcanizing Press EVA Mat Foaming Machine 4 Working Layers

EVA Foam Rubber Sheets Vulcanizing Press EVA Mat Foaming Machine 4 Working LayersEVA Foam Rubber Sheets Vulcanizing Press EVA Mat Foaming Machine 4 Working Layers





Qingdao Honghesheng Industry Co., LTD, manufacturer of rubber machine,which is located in the west coast of Qingdao economic district, with 10 million registered capital. The company covers an area of 5000 square meters with 26 professional and technical staffs and 5 senior engineers. The technical staffs have working experience in large tire enterprise who can design more suitable equipment for the customer as for tire production process. Also they can provide new factory site planning and other services.
The company’s main products are: Rubber kneader, rubber mixing mill, rubber sheet cooling machine, inner tube production line
,tyre production line, vulcanizing press, waste tyre recycling plant…

welcome to visit our factory

EVA Foam Rubber Sheets Vulcanizing Press EVA Mat Foaming Machine 4 Working Layers

EVA Foam Rubber Sheets Vulcanizing Press EVA Mat Foaming Machine 4 Working Layers



. Q: Are you a manufacturer or traiding company?

A: We are the manufacturer. We have our own plant,worker and techniques research developing department.



2 .Q: Where is your factory located? How can I visit there?

A: Our factory add is Tieshan industrial Park, Jiaonan, Qingdao, Shandong province, China.

Nearest airport is Qingdao liuting international airport

Kindly send plane information in advance, so that we can pick you up at the airport, and book hotels as you require.



3. Q: What are your hot sale machine?

A: Our rubber and plastic machines are popular in the foriengn market. And main products are tyre recyling plant and other machine.



4. Q: How does your factory do regarding quality control?

A: Quality is priority and we have our own quality control department. We win make a strick inspectin before the machines leave the factory.



5 .Q: Are the techncal parameter is fixed?

A: Basically, each model corresponding to the related machine. But we can design different type machine according to the client’s requirement.



6 How to send us your enquiry? Kindly tell me answer

-1 what is your EVA sheet width ?



-2 Leave your cellphong? Skype? whatsApp?viber? so that we can talk efficiently







EVA Foam Rubber Sheets Vulcanizing Press EVA Mat Foaming Machine 4 Working LayersEVA Foam Rubber Sheets Vulcanizing Press EVA Mat Foaming Machine 4 Working Layers
